SM-P4: Professional Digital Indicator with 4 inputs

Professional Digital Indicator with 4 inputs, suitable for receiving signals from strain gauge sensors, transmitters with voltage or current output and PT100.
DATALOGGER with non-volatile memory
A rear USB port to connect directly to a PC or Tablet.
4 DIGITAL INPUT 24Vdc with function programmable
5 RELAYS type DPDT
5 programmable SET POINT
OPTIONS : RS232, RS485 modbus, up to 4 programmable Analog Outputs , front panel USB port type A, to export directly on a USB stick a datalogger in csv file.

Log in to your account to display prices
account_circleSend to a friend
SM-P4:  Professional Digital Indicator with 4 inputs

SM-P4: Professional Digital Indicator with 4 inputs

Professional Digital Indicator with 4 inputs, suitable for receiving signals from strain gauge sensors, transmitters with voltage or current output and PT100.
DATALOGGER with non-volatile memory
A rear USB port to connect directly to a PC or Tablet.
4 DIGITAL INPUT 24Vdc with function programmable
5 RELAYS type DPDT
5 programmable SET POINT
OPTIONS : RS232, RS485 modbus, up to 4 programmable Analog Outputs , front panel USB port type A, to export directly on a USB stick a datalogger in csv file.



Each input channels can be supplied in 6 different configurations:

• Version with input for strain gauge transducers
• Version with voltage input with standard resolution
• Version with current input with a standard resolution
• Version with temperature input for PT100 eligible to work in the range from -50 °C to + 250 °C
• Version with incremental ENCODER input suitable for working with linear or rotary encoders. Also you can definewhether to measure angle, displacement or speed.
• Version with POTENTIOMETER input suitable for working with linear transducers or displacement.

SM-P4
